Injection Molding IMD Panel Large Arc Water Purifier shell Accessories

10K pcs
MOQ
$7.3/pcs
Price
Injection Molding IMD Panel Large Arc Water Purifier shell Accessories
Features Gallery Product Description Request A Quote
Features
Specifications
Surface Finish: High Gloss
Advantage: All In One Solution
Material: Pc + Pet
Plastic Modling Type: Forming Mold, Cutting Mold,Injection Mold
Process: In Mold Decoration
Logo: Various Patterns And Colors Can Be Customized And Never Fade
Highlight:

Injection Molding IMD Panel

,

IMD Panel Large

Basic Infomation
Place of Origin: SHENZHEN,CHINA
Brand Name: HXSIMD
Certification: ISO9001/ISO14001/ISO16949/45001
Model Number: IMD-261
Payment & Shipping Terms
Packaging Details: Packaging methods that prevent crushing, moisture, and high temperatures
Delivery Time: 12 work days
Payment Terms: T/T, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 Pieces per Day
Product Description

IMD Panel Of The Large Arc Water Purifier Is Off White With A Lighting Effect That Never Fades

Characteristics of IMD shell accessories for water purifier:

1. Large size and large curvature in appearance;

2. Off white high gloss exterior;

3. Equipped with buckle and other structures inside;

4. The color of the plastic material is transparent, and the material is PC;

5. It also has a lighting effect, which means that the control button characters are visible when the light is on, and only the surface is off-white when the light is off

6. The product materials, ink, and other products are imported from top tier brands, such as Imperial Ink of Japan, Toray of Japan, LG, etc

7. Some other IMD product features have advantages



IMD Panel Product Properties:

Product size 420*300*60mm
Product material PC+PET
Product unit price $7.3
MOQ 10K pcs
Mold Type Injection mold+formming mold+cutting mold=3
Mold  time 28 Work Days
Mold material S136
Mold Life Guaranteed warranty within 500000 times
Daily production capacity   4K pcs
Tonnage of injection molding machine 380T



IMD Panel process introduction:

In Mold Decoration(IMD): use PET film coated on the surface as the carrier to print ink pattern layer, adhesive and ink curing on the printing surface. Then it is heated and baked for hot pressing forming and trimming. Put the shaped PET film into the injection mold cavity through manual or mechanical hand to fill the plastic, and melt the adhesive to bond the PET film with the ink pattern layer to form a whole with the plastic under high temperature.

Expansion area:

In addition to PET materials, it can also be cloth, PU leather, wood chips, bamboo chips and other sheet materials



IMD Panel  product process:

1.Sheet cutting: cut a whole roll of sheet into small pieces

2.Pre-baking: the purpose is to eliminate the stress inside the sheet and make the sheet stretch

3.Printing: print different patterns on the diaphragm

4.Ink curing: curing the ink on the sheet to make the ink highly integrated with the sheet

5.Punching: punch holes in the diaphragm to fix the diaphragm for the next process

6.Cutting: cut the diaphragm into smaller pieces

7.Diaphragm forming: mold the diaphragm into product shape

9.Edge cutting and material removal: cut off the excess edge material

10.In-mold injection molding: put the molded diaphragm into the mold of the injection molding machine to inject plastic

11.Water outlet: remove excess plastic

12.Inspection and packaging:Conduct a comprehensive inspection on the finished products to confirm that the quality is qualified, and then pack them for shipment



IMD Panel product  customization process:

1. The customer provides IMD PARTS data, including the designed three-level diagram and ID effect diagram;

2. Evaluate and confirm the drawings;

3. Both parties sign the mold contract;

4. Pay the first payment of the mold;

5. Start mold production;

6. Proofing;

7. Confirm the sample;

8. Sign order contract;

9. Pay the first payment of the order and the last payment of the mold;

10. Production;

11. Deliver the goods and pay the balance of the order at the same time



Why choose us

We are the first professional IMD PARTS manufacturer in China,Founded in 2009, the company's industrial park covers an area of more than 30000 square meters, has a high-precision dust-free workshop, and has nearly 100 excellent management personnel, 35 engineering and technical personnel, 50 quality personnel, a total of nearly 500 employees, more than 500 injection molding equipment, and a monthly production capacity of nearly 15 million pieces; From engineering research and development to mold production, diaphragm printing, diaphragm molding, diaphragm injection molding, inspection and packaging, there is a complete process production process.

Injection Molding IMD Panel Large Arc Water Purifier shell Accessories 0



Full-process dust-free workshop operation

Injection Molding IMD Panel Large Arc Water Purifier shell Accessories 1



Full-process dust-free workshop operation

Injection Molding IMD Panel Large Arc Water Purifier shell Accessories 2



Our company has won the honors of high-growth enterprise, industry benchmark enterprise, contract-abiding and creditworthy enterprise, high-tech enterprise, etc

Injection Molding IMD Panel Large Arc Water Purifier shell Accessories 3



HXS has become a long-term partner of more than ten top 100 enterprises in the world

Injection Molding IMD Panel Large Arc Water Purifier shell Accessories 4



Injection Molding IMD Panel Large Arc Water Purifier shell Accessories 5
